Socket Welding Flanges
Product Description
The socket welding flange is similar to a slip on flange except it has a bore and a counter bore dimension. The counter bore is slightly larger than the O.D of the matching pipe, allowing the pipe to be inserted into the flange similar to a slip-on flange. The diameter of the smaller bore is the same as the I.D of the matching pipe. A restriction is built into the bottom of the bore which sets as a shoulder for the pipe to rest on. This eliminates any restriction in flow when using a socket welding flange.
Product Features
- Precise counter-bore design for accurate pipe alignment
- Similar to slip-on flanges but with better strength and flow integrity
- Ideal for small-diameter, high-pressure piping systems
- Smooth internal flow with minimal turbulence
- No pipe end beveling required for welding
- External fillet weld provides strong and reliable joints
- Reduced risk of leakage compared to threaded flanges
- Good resistance to fatigue and pressure stress
Specification
| Size | U(mm) | T(mm) |
|---|---|---|
| 1/8” | 10.7 | 40 |
| 1/4” | 14 | 41.2 |
| 3/8” | 17.1 | 41.5 |
| 1/2” | 21.7 | 61.8 |
| 3/4” | 27 | 62 |
| 1” | 33.8 | 62 |
| 1.1/4” | 43 | 82.4 |
| 1.1/2” | 49 | 82.4 |
| 2” | 60.2 | 102.8 |
| 2.1/2” | 77.9 | 103.2 |
| 3” | 90.8 | 122.2 |
| 4” | 115.8 | 122.2 |
